| * Entrance lock approved by EN 12209 | ||||||||
| * Handy | ||||||||
| * Distance between center to center: 72 or 85 mm | ||||||||
| * Backset distances 55,60,65,70, 80 & 100 mm | ||||||||
| * Stainless steel latch, dead bolt and follower SUS 304 | ||||||||
| * Faceplate round or square, 20 or 24 mm | ||||||||
| * Crossing holes for the rose | ||||||||
| * 15 mm long cam profile cylinder, with three keys | ||||||||
| * Stainless steel strike | ||||||||
| * Without rose | ||||||||
| * Deduct €1,50 if the cylinder is not required | ||||||||
| * Deduct €0,60 if the strike is not required |
| reference | function | finish | backset | turns | follower | |||||
| E9610-55 | Entrance | S. S. | 55 | 1 | 8 | |||||
| E9620-55 | Entrance | S. S. | 55 | 2 | 8 | |||||
| E9610-60 | Entrance | S. S. | 60 | 1 | 8 | |||||
| E9620-60 | Entrance | S. S. | 60 | 2 | 8 | |||||
| E9610-65 | Entrance | S. S. | 65 | 1 | 8 | |||||
| E9620-65 | Entrance | S. S. | 65 | 2 | 8 | |||||
| E9610-70 | Entrance | S. S. | 70 | 1 | 8 | |||||
| E9620-70 | Entrance | S. S. | 70 | 2 | 8 | |||||
| E9610-80 | Entrance | S. S. | 80 | 1 | 8 | |||||
| E9620-80 | Entrance | S. S. | 80 | 2 | 8 | |||||
| E9610-100 | Entrance | S. S. | 100 | 1 | 8 | |||||
| E9620-100 | Entrance | S. S. | 100 | 2 | 8 | |||||
